DISOWARE Terra – The Data Management System for Rail Weighbridges
%
Convenient data management on standard Windows PCs
%
Network-compatible in a server-client database environment
%
Multilingual operator prompting
%
Wagon identification via RFID long range tag reader
%
Fully automatic mode possible
%
Data acquisition and remote control in WLAN using hand-held terminal
%
Flexible connection to user’s EDP systems
(Fig. 1)
Application
Functions
The DISOWARE Terra software is designed as data management system for MULTIRAIL® LegalWeight, MULTIRAIL® LiquidWeight and MULTIRAIL® MultiBridge rail weighbridges of Schenck Process.
DISOWARE Terra comes with a host of functions, processes and options for utilisation of your weigh data. • Control of connected dynamic or static rail weighbridge • Easy acquisition, display, edit, evaluation, export, import, print, delete, and search of weigh data • Flexible evaluation tools for individual configuration of database queries • Master data tables for wagons, suppliers, receivers, material types and comments • User management with multiple access privileges • Data safety through integrated mechanisms for saving and restoring of database • Remote control of weighing operation through user’s EDP-systems
Used for control and direct communication with the connected rail weighbridge, this software lets you process your weigh data with utmost ease and interface any EDP-system available in your plant. The use of an SQL database ensures maximum data safety both with single user systems and in the network of a multi-user environment.
• •
•
• •
•
•
BV-D2216GB
Fully automatic mode with no need for operator intervention Integrated wagon identification with the use of RFID-tags and appertaining long range tag reader system (<10 m reach) Integrated wagon monitoring system for evaluation of wheel and axle loads using defined limit values Remote maintenance and update options for complete software Automatic recognition of first and second weighing with subsequent NET weight computation Data acquisition and remote control of scale in WLAN using rugged industrial hand-held terminal Empty-state check weighing with automatic update of TARE weight in wagon master file
Weighing Mode Fig. 1 depicts the DISOWARE Terra main window that readies all functions required for easy handling of connected scale and acquired weigh data. • Convenient acquisition of train data complete with • Wagon number, including check number check • Material, supplier, receiver, comments • Up to 3 containers with declared tare • Order, shipper and track numbers, NHM code • Input of first, second or tare weighing for each single wagon •
•
Acquired weight is stored in wagon file complete with data, so that empty weight can be checked
DISOWARE Terra Modules The functions of the various modules partially depends on available hardware. •
Convenient editing of acquired train lists: • Wagon arrangement, weighing mode and all assigned data • Train explorer (Fig. 2) for convenient assembly of new train from existing data by mouse click
During weighing, the wagon monitoring function checks speed, highest wagon axle load, wagon side and front/rear ratios using defined limit values. Any excess is output on report monitor, reported via digital output and can be printed in form of an error report (Fig. 3). Weigh data are assigned to acquired train data, so that load limit can be checked for compliance with limit value from wagon file, reported and printed.
(Fig. 3) •
The wagon identification function comprises one or multiple long range RFID-tag reader system(s) and a semi-passive tag attached to every wagon (see Fig. 4). Using the ID stored in the RFID-tag wagon data are read from master data, train is automatically formed, and train list with wagon number is printed and stored.
(Fig 2) •
Fast-track acquisition function for trains with wagons containing same load for same receiver
•
Dynamic and static weighing control functions; data acquisition possible during weighing
•
Train weighing before acquisition of train data. Acquired train data can be assigned also after weighing
•
To save input time, wagons to be left out can be marked after weighing (no data acquired)
•
Trains can be weighed partially and comprised to form a new train at a later time
(Fig. 4) •
The DISPO EDP connection readies an interface based on the exchange of ASCII files. DISOWARE Terra uses supplied file to form the train list that can be completed by the operator. After weighing, software assigns weigh data, prints train list and writes result file.
•
The DEBIS EDP connection enables complete control of scale including feedback of weigh data via serial interface (Fig. 5). The protocol offers freedom of adaption; standard S3964R is also realised. No PC intervention is necessary.
(Fig. 7)
(Fig. 5) •
The MQ Series EDP connection lets you realise a • fully automatic scale. Weighing is started via a rail switch for any direction of travel. When weighing is complete, data are entered into the MQ series message queue and are available for further processing by user. Scale status also enters into message queue in cycles.
•
The SAP R/3 EDP connection can be realised via IDoc standard interface. Wagon arrangement can be adopted from SAP R/3, or weighing results transferred to SAP R/3.
•
EDP connections to Oracle databases with data acquisition and transfer are realised as well.
•
The Evaluation/Export EDP connection readies CSV files in ASCII format using freely definable SQL commands.
•
Mobile data acquisition and remote control of scale can be effected on rail direct, or started by the engine driver via a rugged industrial hand-held terminal (Fig. 6) or commercial PDA. The handheld terminal lets you acquire complete trains and start weighing. A PC can be connected using the cost-effective open WLAN 2.4 GHz or the coordinated frequencies 450 MHz ... 470 MHz. Data can also be acquired in the form of a web application, with inputs being made via Internet Explorer.
The Balance window (Fig. 8) readies functions for preparation of evaluations, e.g. a material throughput statistic for a certain supplier over an optional period of time.
(Fig. 8) •
For convenient acquisition of master data, acquisition screens (Fig. 9) are available for all master data tables. These screens represent single data records in a set form. Compared to table input, these forms are much easier to handle.
(Fig. 9) • (Fig. 6) • The weighing file stores all previously effected weighing operations (Fig. 7). The window prompts for input of period, wagon, customer, material type, supplier and product. These data can be combined • at will, so that simple reports, e.g. by shift or customer, can be displayed and printed.
Backup and Restore For the sake of data safety, a database safety copy should be prepared regularly. To do so, you can use the backup function that lets you save data on a predefined backup medium. In case of data loss, the Restore function lets you return to the state at the time of data saving. The DISOSAVE program lets you store weigh data legal-for-trade (Data Sheet BV-D2045) and is approved for legal-for-trade storage on PC throughout the European Community.
Relevant Data Sheets BV-D2142 BV-D2279 BV-D2221 BV-D2045 BV-D2066 BV-P2050
Special Configurations DISOWARE Terra special configurations can be offered at any time, e.g. - Connection to your EDP system - Adaption to existing processes
Please let us know your requirements, we will gladly provide you with a tailored solution.
Schenck Process GmbH Pallaswiesenstr. 100 64293 Darmstadt, Germany Phone: +49 6151 1531-3431 Fax: +49 6151 1531-1043
[email protected] www.schenckprocess.com
BV-D2216GB 1135 All information is given without obligation. All specifications are subject to change. © by Schenck Process GmbH, 2011
